Technical Specifications
Technical specifications for Victory 9:
-
Weight capacity: 300 lbs (136 kg)
-
Maximum speed: 5.25 mph (8.45 kph)
-
Overall scooter width: 22.25” (565.15 mm)
-
Seat-to-ground height range: 19.25” – 20.75” (488.95 mm – 527.05 mm)
-
Rear tires dimensions: 3” x 9” (76.2 mm x 228.6 mm)
-
Range per charge: 13 miles (21 km)
-
Seat dimensions: 18” x 17” (457.2 mm x 432 mm)
-
Drive system: Rear-wheel drive, sealed transaxle with 24V DC motor
-
Battery: 12V deep cycle, U-1
Technical specifications for Victory 10:
-
Weight capacity: 400 lbs (181 kg)
-
Maximum speed: 5.25 mph (8.45 kph)
-
Overall scooter width: 22.25” (565.15 mm)
-
Seat-to-ground height range: 20.5” – 22” (521 mm – 559 mm)
-
Front tires dimensions: 3.5” x 10” (89 mm x 254 mm)
-
Rear tires dimensions: 3.5” x 10” (89 mm x 254 mm)
-
Range per charge: 15.5 miles (25 km)
-
Drive system: Rear-wheel drive, sealed transaxle with 24V DC motor
Technical specifications for Victory 10 LX with CTS Suspension:
-
Weight capacity: 400 lbs (181 kg)
-
Maximum speed: 5.6 mph (9 kph)
-
Turning radius: 59.9” (1521.5 mm)
-
Overall scooter length: 47” (1194 mm)
-
Overall scooter width: 22.2” (564 mm)
-
Seat-to-ground height range: 23.25” – 24.75” (590.6 mm – 628.7 mm)
-
Front tires dimensions: 3.5” x 10” (89 mm x 254 mm)
-
Rear tires dimensions: 3.5” x 10” (89 mm x 254 mm)
-
Range per charge: 16.16 miles (26 km)
-
Drive system: Rear-wheel drive, sealed transaxle with 24V DC motor
-
Battery: 12V deep cycle, 40 AH
-
Unit weight (without batteries): 179 lbs (81.2 kg)
Technical specifications for Victory 10 Sport:
-
Weight capacity: 350 lbs (159 kg)
-
Maximum speed: 8 mph (13 kph)
-
Turning radius: 51.75” (1314.45 mm)
-
Overall scooter length: 47” (1194 mm)
-
Overall scooter width: 26” (660.4 mm)
-
Seat-to-ground height range: 21.5” – 24.25” (546.1 mm – 616 mm)
-
Front tires dimensions: 3.5” x 10” (89 mm x 254 mm)
-
Rear tires dimensions: 4” x 10” (101.6 mm x 254 mm)
-
Range per charge: 11 miles (17.7 km)
-
Drive system: Rear-wheel drive, sealed transaxle with 24V DC motor
-
Battery: 12V deep cycle, 40 AH
-
Unit weight (without batteries): 173 lbs (78.5 kg)
Product Options
Options for all Pride Victory Series models:
-
Cane clip attachment – Attaches to the armrest for easy cane storage on the scooter
-
Cup holder – Attaches to the armrest for easy drink storage on the scooter
-
Double can holder – Attaches to back of the seat for easy storage of multiple canes
on the scooter
-
Oxygen holder – Attaches to back of the seat for easy storage of oxygen tank on
the scooter
-
Ram X-Grip cell phone holder – Attaches above tiller for easy phone storage on scooter
-
Rearview mirror – Attaches to the handlebar for rearview vision
-
Saddlebag – Attaches to the headrest for additional storage on the scooter
-
Safety flag – Attaches to scooter and provides a visual alert for pedestrians
-
Single cane holder – Attaches to back of the seat for easy cane storage on the scooter
-
Touch-up paint – Extra paint to cover up paint transfers or nicks on the scooter
-
Walker holder – Attaches to back of the seat for easy walker storage on scooter
-
Weather breaker – Drapes over scooter for scooter protection when not in use
-
Weather cover – Attaches to back of the seat for sun and precipitation protection outdoors
-
Wishbone crutch holder – Attaches to back of the seat for easy crutch storage on the scooter
Options for Victory 9, Victory 10, and Victory Sport models only:
-
Color – Available in two colors for added style:
- Candy Apple Red
- Viper Blue
Options for Victory 9 and Victory Sport models only:
-
Lapbelt – Attaches to seat for secure user restraint during scooter operation
Options for Victory 10 LX with CTS Suspension and Victory Sport models only:
-
Seat size – Seat available in two different sizes for optimum customization:
- 18” x 18” (457.2 mm x 457.2 mm)
- 22” x 18” (559 mm x 457.2 mm)
Options for Victory 9 model only:
-
Wheels – Available in two different wheel configurations for optimum
customization:
-
Three-wheel
-
Turning radius: 40.25” (1022.35 mm)
-
Overall scooter length: 43.5” (1105 mm)
-
Front tires dimensions: 3” x 8” (76.2 mm x 203.2 mm)
-
Unit weight (without batteries): 117.5 lbs (53.3 kg)
-
Four-wheel
-
Turning radius: 51.5” (1308.1 mm)
-
Overall scooter length: 45.5” (1156 mm)
-
Front tires dimensions: 3” x 9” (76.2 mm x 228.6 mm)
-
Unit weight (without batteries): 131 lbs (59.4 kg)
Options for Victory 10 model only:
-
Battery size – Battery available in two different sizes for optimum
customization:
-
Seat size – Seat available in three different sizes for optimum customization:
- 18” x 17” (457.2 mm x 432 mm)
- 18” x 18” (457.2 mm x 457.2 mm)
- 22” x 18” (559 mm x 457.2 mm)
-
Wheels – Available in two different wheel configurations for optimum
customization:
-
Three-wheel
-
Turning radius: 42” (1067 mm)
-
Overall scooter length: 45.25” (1149.35 mm)
-
Unit weight (without batteries): 133.5 lbs (60.6 kg)
-
Four-wheel
-
Turning radius: 54” (1372 mm)
-
Overall scooter length: 47” (1194 mm)
-
Unit weight (without batteries): 137.5 lbs (62.4 kg)
Options for Victory 10 LX with CTS Suspension model only:
-
Color – Available in two colors for added style:
- Candy Apple Red
- True Blue
